Datalogic IO-Link S8 User Manual

PROCESS DATA
DEVICE VARIANT COLLECTION
Bit o󰀨set
Process Data Input
Byte 0
7 6 5 4 3 2 1 0
Not used ALARM (B53)
COUNTER EXCEED
THRESHOLDS
TEACH-IN SSC2 (DO pin) SSC1 (C/Q pin)
Product name Product ID Product text
S8-PR-5-W03-0Z 00004 Contrast sensor
S8-PR-5-T53-0Z 00005 Reex transparent
S8-PR-5-B53-OZ 00006 Reex polarized laser
S8-PR-5-U03-OZ 00007 Luminescence sensor
Switch Counter
Index
(dec)
Parameter
Object Name
Lenght
Subindex
(o󰀨set)
Value/Range Description Data Type Access* Remark
0x00B6 (182)
Switch counter
settings
1 octet
1 octet
2 octets
1(24)
2(16)
3(0)
0: OFF (default)
1: Counter (STATIC)
2: Counter (AUTO)
0: Output Rising Edge (default)
1: Output Falling Edge
0-65535 (default = 0)
Mode
Trigger counter
Threshold counter
UIntergerT
Boolean
UIntegerT
RW
RW
RW
Saved in non-volatile memory.
Stop or reset the running counter
before changing conguration, then
re-enable the counter with Set counter
commands.
*Rising and falling egdes are referred
to DO pin.
0x00B7 (183)
Switch counter
values
1 octet
2 octets
1(16)
2(0)
0: counting UP (default)
1: counting DOWN
2: counting INACTIVE
-32,768..32,767
Counting direction
Switch counter value
UIntegerT
IntegerT
RO
RO
EXTENDED PARAMETERS
Index
(dec)
Parameter
Object Name
Lenght
Value
(dec)
Description Access
0x0002 (2) Reset counter 1 octet 0xA0(160) Reset counter value WO
0x0002 (2) Enable counter UP 1 octet 0xA1(161) Enable counter and start count UP (counter value is not reset. Reset counter command to zero the value) WO
0x0002 (2)
Enable counter
DOWN
1 octet 0xA2(162) Enable counter and start count DOWN (counter value is not reset. Reset counter command to zero the value) WO
0x0002 (2) Stop counter 1 octet 0xA3(163) Freeze the counting functions (all commutations are neglected: counting INACTIVE). Enable counter to resume the counting function. WO
