System Connections
14 BC9600/BC9620 BASE STATIONS
ETHERNET
NOTE: When using the BC9680/BC9681 cradles, apply the ferrite pro-
vided with the device to the Ethernet cable 5 cm from the cradle. See
the example below.
BC9620/BC9631
BC9680
BC9681
POE connection
BC9681
External Power Supply
Brown: +10/30 VDC
Blue: GND
Black: Not Used
