Portable Desktop Mounting
6
BC9600 BASE STATIONS
3. Rotate the tab until you will see "WALL" tooth, put the rotated tab into
place and secure it with the screw.
PORTABLE DESKTOP MOUNTING
For desktop mounting, if portability of the base station is required, the
mounting plate can be used. There are two ways this can be done: (1) base
station fast release by first fixing the mounting plate onto a flat surface so the
base station can be slid off and on, or (2) connection module fast release by
fixing the mounting plate to the connection module and then fixing both of
them onto a flat surface so only the cradle can be slid off while the connection
module will remain on the desk.
Base Station Fast Release - Mounting the Plate
1. Affix the mounting plate onto the desired mounting surface using four
screws through the holes highlighted in the figure below.
