Quick Reference Guide 1
PowerScan™ PD8300
Using the PowerScan™ PD8300
PowerScan™ PD8300 readers automatically scan barcodes at a distance. Simply
aim and pull the trigger. Code scanning is performed along the scan line emitted
from the reading window. This line must cross the entire code. The best reading
angles are indicated in the figure below.:
Aiming System
The PowerScan™ PD8300 provides an aiming system. If enabled, a partial trigger
press produces a red spot, which should be aimed over the code center to get the
best reading performance, see figure (1) above. By completely pressing the trigger
the scan line appears to start code scanning (2).
After setting up the reader, you can enable or disable the aiming system by reading
the codes below:
Disable Aiming System (Default)
Ì$+Bj0$-"Î
Enable Aiming System
Ì$+Bj1$-'Î
