Datalogic PowerScan PM9500 series User Manual

Linking the Reader
Quick Reference Guide 9
Linking the Reader
Link Datalogic RF Devices to Base
For RF devices, before configuring the interface it is nec-
essary to link the handheld with the base.
To link the handheld and the base, press the trigger to
wake up the handheld, and mount it on the base. If the
reader was previously linked to another base, you must
first scan the
Unlink bar code before re-linking to the new
base.
Unlink
Power Off
Scan the bar code below to shut off power to the BT hand-
held until the next trigger pull.
PowerOff

Datalogic PowerScan PM9500 series Specifications

General

Connectivity	Cordless
Sealing	IP65
Light Source	LED
Image Capture	Yes
Battery Type	Lithium-Ion
Weight	400 g / 14.1 oz
Radio Range	Up to 100 m / 328 ft
Radio Frequency	433 MHz
Drop Resistance	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
Supported Symbologies	1D, 2D, Postal
Interface	RS-232, USB, Keyboard Wedge
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Storage Temperature	-40 to 70 °C / -40 to 158 °F
Humidity	5 to 95% non-condensing
Dimensions	212 x 110 x 74 mm / 8.3 x 4.3 x 2.9 in
Power Supply	External power adapter
