Technical Specifications
26
POWERSCAN™ PM/PBT9600
DOF - DEPTH OF FIELD (TYPICAL)
A
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Symbology DOF range
Code 128
PM/PBT9600-SR:
5 mils: 6.4-30.9 cm (2.5-12.2 in)
20 mils: 4-103.7 cm (1.6-40.8 in)
40 mils: 5.5-175 cm (2.2-68.9 in)
PM/PBT9600-HP:
2.5 mils:6.3-11.5 cm (2.5-4.5 in)
5 mils: 3.8-41 cm (1.5-16.1 in)
20 mils: 4-157 cm (1.6-61.8 in)
40 mils: 5.5-242.9 cm (2.1-95.6 in)
EAN13
PM/PBT9600-SR:
13 mils: 4-67.5 cm (1.5-26.5 in)
PBT/PM9600-HP:
13 mil: 4-120.2 cm (1.5-40.2 in)
PDF417
PM/PBT9600-HP:
10 mils: 0.5-46.1 cm (0.2-18.1 in)
Data Matrix
PM/PBT9600-SR:
10 mils: 6.4-30 cm (2.5-11.8 in)
PM/PBT9600-HP:
4 mils: 6.5-9.3 cm (2.5-3.6 in)
10 mils: 4.2-32.1 cm (1.6-12.6 in)
Max Resolution
b
b. 1D codes are Code 39 and 2D codes are Data Matrix
PM/PBT9600-SR:1D = 3 mils, 2D = 6 mils
PM/PBT9600-HP:1D = 2.5 mils, 2D = 4 mils
