Datalogic QuickScan i QD2100 Quick Reference Guide

8QuickScan
TM
i
Programming Barcodes
For your convenience, this guide includes the programming
barcodes required to configure the imager for use with different
interface (terminal/host) types.
See the Product Reference Guide (PRG) for more complete in-
formation about programming and configurable features. You
can download the latest version of the PRG and any other avail-
able publications for the imager from the website listed on the
back cover of this manual.
Resetting the Standard Product Defaults
If you aren’t sure what programming options are in your imag-
er, or you’ve changed some options and want the factory set-
tings restored, scan the Factory Default Settings barcode below.
This will copy the factory configuration for the currently active
interface to the current configuration.
Factory Default Settings
Host Interfaces
NOTE
Cables may vary depending upon sys-
tem configuration.
Some interfaces require the imager to
start in the disabled state when pow-
ered on. If additional imager configura-
tion is desired while in this state, pull
the trigger and hold it for five seconds.
The imager will change to a state that
allows programming with barcodes.

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
