iBoot Page 13
Specifications
Model
iBoot A/C Power Control Module SKU: 1410010
Physical
Height 2.25 in.
Width 4.50 in.
Depth 6.00 in.
Weight 1.25 lb.
AC
Input: 3 Prong, Male, IEC 320 input connector.
Input Cord Spec...16AWGX3C 10A 250 UL/CSA/VDE Rated
(1.25mm
2
X3C)
Voltage Range: Selectable 105-125VAC or
210-240VAC 50/60 Hz
Switched Receptacle: 3 Prong Female IEC
Capacity: 12 Amps Max @ 125VAC, 10Amps Max at 240VAC
Network
Dual 10/100 Unshielded Twisted Pair Ethernet Jacks.
IP Addressed
HTTP Web Browser Controlled,
Forms Processing Browser required
