Front Panel
HD/SD - SDI Input & Output (bypass)
SDI provides video signals for professional applications
and allows long distance signal transmission.
Left BNC connector: HD/SD-SDI Input
Right BNC connector: Loop Thru Output
RCA Input
Two channels of Unbalanced L / R Audio input
Note: One of SDI Audio or RCA Audio input is
embedded into HDMI Signal
