8
2. There are four adhesive Velcro straps are packed
inside item H. Peel off the white paper backing
before applying these straps to the Glass Frame,
item F. Apply the two long Velcro strips to the
Glass Frame edges Left side and Right side. Now
apply the two smaller Velcro strips to the Bottom
Left and Right sides of the Glass Frame edge. Be
careful to keep them straight.
3. Slide the Glass frame, item F, on to the upper part
of the prompter frame, item A, and secure with two
wing nut screws, item G.
4. Guide/slide 60/40 Glass sheet, item I, into the
Glass frame, item F.
The Red circle sticker should be facing camera
position / lens.
The Green circle sticker should be facing toward
the on screen talent / commentator.
