9
5. Apply the black camera Snood/Hood, item H, to the
Glass Frame edges, item F, so the Velcro strips
marry the Snood/Hood to the Glass Frame.
6. At this point decide if you want to fit the optional
side curtains. Generally the side curtains should
only be fitted when working in direct sunlight. The
side curtains are applied to each side of the frame
first then the Snood/Hood is fitted over the top edge
of each side curtain. The curtains can help stop
light from being reflected either off the mirror 60/40
glass or tablet.
7. Decide if camera riser blocks, item K, are required
depending on the position of the camera lens. If
using 1 block use the short hex screws, item M,
through one block but leave the centre hole empty.
Turn the block over so that screws project
downwards and sit in the long slot on top of the
prompter frame, item A.
