Page #10 background image
Fiscal Printer DATECS FP-2000 Version 3.10
Switch OFF ON
1
Select RS232 speed
2
Select RS232 speed
3
Select RS232 speed
4
Normal mode “Transparent display” mode
5
Automatic paper cutting off Automatic paper cutting on
5
Half cut Full cut
6
Not used
7
Not used
Sw1 Sw2 Sw3 Speed
0 0 0 1200 bps
0 0 1 2400 bps
0 1 0 4800 bps
0 1 1 9600 bps
1 0 0 19200 bps
1 0 1 38400 bps
1 1 0 57600 bps
1 1 1 115200 bps
2AH (42) PRINTING OF A FREE NON-FISCAL TEXT
Data field: Text
Response: None
Text A text of 40 symbols (at most). The symbols after 40 are cut off.
If S1.1 is raised there is no non-fiscal receipt opened and the text is not printed.
2BH (43) SETTING HEADER, FOOTERS AND PRINTING OPTIONS
Data field: <Item><Text>
Response: None or current settings in case of Item =I’
Footer consists of 2 lines of text printed at the end of each receipt. It is automatically centered.
Item One symbol having the following meaning:
“0” to “7” 0 to 5 are the HEADER lines, 6 and 7 are the FOOTER lines.
“B Set bar code height in pixels (0.125 mm). Possible values from 24 (3 mm) to 240 (30 mm).
The barcode is printed with command 84 (54H).
“C” Permission/rejection of the automatic cutting of paper after each receipt. After switching
ON, the performance of printer is defined in accordance with the setting of the switch SW5.
“D” Set print darkness. Possible values:
1’: Very low
2’: Low
3’: Normal
4’: Dark
5’: Very dark
“E” Enable / disable the printing of the total in EUR when executing the first payment
command (53) in the fiscal receipt. By default this option is forbidden. Optionally the
command programs the exchange rate EUR / LEKI. Data syntax:
<Enable>[,Rate]
Enable Flag disable / enable printing. One symbol: 0’ or ‘1’.
Rate Exchange rate. Floating point number with up to 8 significant digits and 5 decimals. If this
field missing, the old value is used. If the value is 0.00000, then nothing is printed
independent on the value of Enable flag.
“L Permission/rejection and height of graphic logo of the printing of graphic logo immediately
before the header. This logo is defined with command 115 (73H).
“T” Enable / disable printing of accumulated VAT values in a non-invoice type fiscal receipt.
“X” Enable / disable automatic cash drawer pulse in commands 53 (35H) and 70 (46H).
