j Data for imaging. The format is similar to the generation
of text and barcode and is described further in the text.
When the barcode functions with a set number of
symbols the command will be rejected at an
unacceptable symbol. The same is valid in the case of
invalid barcode lengths demanding a certain number
of symbols.
Example: B0,0,0,E30,2,3,60,B,”123456789012"
Will create a barcode image of the EAN13 type with a
starting coordinate (0,0), not rotated, with bars 2 dots
wide, 60 dots high with a duplicating text with content:
“123456789012”.
Table 1:
String Bar code type
3 Code 39
3C Code 39 with check digit
9 Code 93
0 Code 128 UCC
1 Code 128 auto A,B,C modes
K Codabar
E80 EAN8
E82 EAN8 2 digit add-on
E85 EAN8 5 digit add-on
E30 EAN13
A30 EAN13 with internal control digit
E32 EAN13 2 digit add-on
E35 EAN13 5 digit add-on
2G German Post Code
2 Interleaved 2 of 5 (ITF)
2C CInterleaved 2 of 5 with mod. 10 check digit
2D Interleaved 2 of 5 with human readable check digit
P Postnet
1E UCC / EAN 128
UA0 UPC A
UA2 UPC A 2 digit add-on
UA5 UPC A 5 digit add-on
UE0 UPC E
UE2 UPC E 2 digit add-on
UE5 UPC E 5 digit add-on
2U UPC interleaved 2 of 5
L Plessey (MSI-1)
Example: A10, 10, 1, 3, 2, 2, N, “Something”
Will create an image of the text “Something” from the
coordinate (10,10) rotated to 90
o
with font 12 x 20
multiplied times 2 in a horizontal and vertical direction.
The text is not inverted.
Generating barcodes
The command is used for inserting a barcode in the image.
Format: Ba,b,c,d,e,f,g,h[i],j
a Starting coordinate on X for the upper left angle of
t he text: 0 - 2047.
b Starting coordinate on Y for the upper left angle of
the text: 0 - 4095.
c Text orientation: 0=0, 1=90
o
, 2=180
o
, 3=270
o
where rotation is clockwise.
d Selection of the type of barcode for printing - text
from 1 to 3 symbols. The possible values are in
Table 1.
e Setting the thickness of the narrow bar in dots.
Possible values: 1 - 6.
f Setting the thickness of the wide bar in dots.
Possible values 2 - 10, where the value must be
bigger than the previous parameter. Some of the
barcode demand additional restrictions.
g Height of the barcode in dots. Possible values are
between 24 and 1000.
h Duplicate information in textual form or not.
Possible values:
N no
B yes
i A non-compulsory parameter, showing th
alignment of the duplicating text in relation to the
barcode. Accepted only if the preceding parameter
has a B value. Possible values:
C centered
R right aligned
By default the text is left aligned.
