EN Dateq BCS70 Manual BCS78 master (monitor) module 18
BCS78 Inserts (Sub-D 9-pin female)
Pin Function Type
1 Frame GND FRAME
6 Send Right + (no insert used: connect to pin 7) Out
2 Return Right - (no insert used: connect to pin 3) In
7 Return Right + (no insert used: connect to pin 6) In
3 Audio GND (no insert used: connect to pin 2) A-GND
8 Send Left + (no insert used: connect to pin 9) Out
4 Return Left - (no insert used: connect to pin 5) In
9 Return Left + (no insert used: connect to pin 8) In
5 Audio GND (no insert used: connect to pin 4) A-GND
BCS78 Air / Spare 1 / Spare 2 (Sub-D 15p female)
Pin Function Type
1 Air GND A-GND
9 Air Right + In
2 Air Right - In
10 Air Left + In
3 Air Left - In
11 Spare 1 GND A-GND
4 Spare 1 Right + In
12 Spare 1 Right - In
5 Spare 1 Left + In
13 Spare 1 Left - In
6 Spare 2 GND A-GND
14 Spare 2 Right + In
7 Spare 2 Right - In
15 Spare 2 Left + In
8 Spare 2 Left - In
