1: Introduction
PRC-BC4-MS 1-3
BB-LA6 Battery Specifications
CY-2562 Battery Box Specifications
Environmental
Temperature
Operating
0° to +60°C (ambient)
Characteristic Description
Characteristic Description
Electrical
Nominal capacity 6 Ah
Nominal voltage 12 VDC
Max. instantaneous
output current
30A at 20°C
Max. continuous output
current
7A at 20°C
Internal resistance 0.02 ohm max. (fully charged)
Percent of original
capacity versus storage
time
90% after 3 months
80% after 6 months
60% after 12 months
Mechanical
Weight 5.5 lbs. (2.5 kg)
Size (HWD) 3.7 in. x 9.5 in. x 2.3 in.
(9.4 cm x 24.2 cm x 5.8 cm.)
Characteristic Description
Mechanical
Weight 0.5 lbs. (0.23 kg)
Size 3.0 in. x 4.0 in. x 11.0 in.
(7.5 cm x 10 cm x 28 cm.)
