Datron PRC-BC4 - Specifications

1: Introduction
1-2 PRC-BC4-MS
1.2 Specifications
PRC-BC4 Specifications
Note: All specifications subject to change without notice or obligation.
Characteristic Description
General
Input voltage 110/220 VAC or 20 to 30 VDC
Input current 1A (max.) at 110 VAC
0.5A (max.) at 220 VAC
5A (max.) at 20 to 30 VDC
Input protection Fully protected on DC input and battery outputs
Electrical
Bulk charging rate 1.1A (C/5)
Bulk to overcharge
transition voltage
14.0 VDC
Overcharge terminate
current
110 mA (c/50)
Float charge voltage 13.3 VDC
Float to bulk transition
voltage
12.0 VDC
Temperature coefficient
on voltage levels
-12 mV/°C
Current drain on battery
with power off
5µA (max.)
Nominal charge time with
80% discharged battery
6 hrs
Mechanical
Weight 4.3 kg (9.5 lbs.)
Size (HWD) 4.0 in. x 9.5 in. x 11.0 in.
(10 cm x 24 cm x 28 cm.)
Panel indicators POWER ON and FAULT, CHARGING, and READY
for each charger circuit
Operating controls POWER switch, RESET button for each charger
circuit
