4: Technical Description
PRC-BC4-MS 4-7
Table 4-1 Charger Board Parts List (PRC-BC4CHG Rev. T)
Designator Part Number Description
C1 254224 “CAP, 0.22UF POLY 100V 5% 11X13X10LS”
C10 254224 “CAP, 0.22UF POLY 100V 5% 11X13X10LS”
C11 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C12 230020 “CAP,2.2MF ELECT”
C13 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C14 230502 “CAP,4700MF 35V ELECT”
C15 230502 “CAP,4700MF 35V ELECT”
C16 230502 “CAP,4700MF 35V ELECT”
C17 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C18 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C19 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C2 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C20 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C21 230020 “CAP,2.2MF ELECT”
C22 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C23 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C24 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C25 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C3 230020 “CAP,2.2MF ELECT”
C4 254224 “CAP, 0.22UF POLY 100V 5% 11X13X10LS”
C5 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C6 230020 “CAP,2.2MF ELECT”
C7 254224 “CAP, 0.22UF POLY 100V 5% 11X13X10LS”
C8 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C9 230020 “CAP,2.2MF ELECT”
D1 320103 “DIODE, 1N5400 3A 50V DO-201AD”
D10 320002 “DIODE, 1N4148/1N4150 DO-35”
D11 320002 “DIODE, 1N4148/1N4150 DO-35”
D12 320002 “DIODE, 1N4148/1N4150 DO-35”
D13 320002 “DIODE, 1N4148/1N4150 DO-35”
D2 320103 “DIODE, 1N5400 3A 50V DO-201AD”
