4: Technical Description
PRC-BC4-MS 4-9
R22 144002 “RES, 0.22 OHM 1W 5% MOX”
R23 124104 “RES, 100K OHM, 1/4W, 5%, CF”
R24 127104 “RES, 100K MF 1/4W 1% TH”
R25 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R26 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R27 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R28 124103 “RES, 10K OHM, 1/4W, 5%, CF”
R29 124391 “RES,390 OHM 1/4W 5% CF”
R3 127334 “RES, 330K OHM 1/4W 1% MF”
R30 124391 “RES,390 OHM 1/4W 5% CF”
R31 124391 “RES,390 OHM 1/4W 5% CF”
R32 124391 “RES,390 OHM 1/4W 5% CF”
R4 144002 “RES, 0.22 OHM 1W 5% MOX”
R5 124104 “RES, 100K OHM, 1/4W, 5%, CF”
R6 127104 “RES, 100K MF 1/4W 1% TH”
R7 127203 “RES, 20K OHM 1/4W 1% MF”
R8 124104 “RES, 100K OHM, 1/4W, 5%, CF”
R9 127334 “RES, 330K OHM 1/4W 1% MF”
U1 330325 “IC, UC3906N”
U2 330325 “IC, UC3906N”
U3 330325 “IC, UC3906N”
U4 330325 “IC, UC3906N”
U5 330030 “IC,LIN,LM324N,DIP14,OP-AMP”
XU1 621004 “SOCKET, IC DIP-16 PIN”
XU2 621004 “SOCKET, IC DIP-16 PIN”
XU3 621004 “SOCKET, IC DIP-16 PIN”
XU4 621004 “SOCKET, IC DIP-16 PIN”
XU5 621005 “SOCKET, IC DIP-14 PIN”
Table 4-1 Charger Board Parts List (PRC-BC4CHG Rev. T)
Designator Part Number Description
