Datum Systems PSM-500 - Table 3-8. Interface Parameter Detail

PSM-500/500L/500LT SCPC Satellite Modem Operation
PSM-500/500L/500LT - Rev. 0.91
Page 3-25
Table 3-8. Interface Parameter Detail
Interface Parameter Detail
Representation
Type
Entry
Description
Status I/O
Online
Read Only N/A Interface Status **
Status RTS
Off
Read Only N/A Interface RTS line status
Status CTS
On
Read Only N/A Interface CTS line status
Status DCD
On
Read Only N/A Interface DCD line status
Status DTR
Off
Read Only N/A Interface DTR line status
Status DSR
Off
Read Only N/A Interface DSR line status
Status Test
Mod BER
Read Only N/A Interface Test status
Status BER
0.0 E-7
Read Only N/A Interface Test status
Status Sync Loss
3
Read Only N/A Interface Test status
Status Errors
7
Read Only N/A Interface Test status
Status Bits
1.45 E7
Read Only N/A Interface Test status
Status EFS
99.95%
Read Only N/A Interface Test status
Status Erred Sec
1
Read Only N/A Interface Test status
Status Total Sec
2135
Read Only N/A Interface Test status
I/O Mode
RS-449
Selection 0 = Disable
1 = RS-232
2 = RS-449
3 = RS-449/Unterm
4 = V.35
5 = V.36
6 = EIA-530
7 = EIA-530A
8 = SnIP (Option)
9 = HSSI (Option)
Interface electrical mode.
Some option interfaces may
replace the SnIP or HSSI
interface.
Other options may include
G.703 (when released)
I/O RTS
Ignore
Selection 0 = Normal
1 = Control CXR
2 = Ignore
Interface RTS line control
I/O CTS
Normal
Selection 0 = Normal, 1 = Force Active Interface CTS line control
I/O DCD
Normal
Selection 0 = Normal, 1 = Force Active Interface DCD line control
I/O DTR
Normal
Selection 0 = Normal, 1 = Ignore Interface DTR line control
