Datum DTR30G User Manual

14
ROTARY LASER LEVEL
TROUBLESHOOTING
ISSUE POSSIBLE CAUSE AND SOLUTIONS
Laser does not turn on
Check batteries. Make sure batteries are installed according to the
correct polarity.
The batteries may be low or depleted. Make sure the batteries are in
proper working condition. If in doubt, try installing new batteries.
If the laser has been stored in extremely hot temperatures, allow it to
cool.
Laser does not level
Instrument may be outside it’s levelling range. Position the
instrument, tripod or the base surface.
Instrument may have impact damage. Contact service centre for
repair and calibration.
Instrument may be outside its self-levelling range. Adjust the position
within the self-levelling range.
Instrument may be in Manual Mode. The laser must be in Automatic
Mode to self level.
Laser beam distance is reduced Dirt and dusty condition can reduce the visibility of the laser beam.
Clean the laser output window.
Laser head does not rotate Instrument may be levelling or in Wind Mode. Refer to “Direction of
U s e ”.
Laser detector is not working
properly
The detector may be low in battery. Replace batteries and install
according to the correct polarity.
The detector may be out of usable range. Move the detector closer to
the instrument.
PRODUCT LABELS
DTR30R DTR30G
Battery: 4 x 1.5V C-Cell
Ni-MH 4 x 1.2V 4000mAh
Part #: DTR30R
DATUM - 20 THACKRAY ROAD PORT MELBOURNE VIC 3207
ROTARY
LASER
SERIAL #
CAUTION: LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
ACCORDING TO IEC/EN 60825-1:2014
MADE
IN CHINA
Check piece count, headings, photos
& illustrations match on all panels
Compliance
Barcode Scans
Country of Origin
Pronto Code All Panels
Part Number All Panels
Update Details in Pronto
Supplier Contact Correct
Update Product Specication Sheet
Category
Manager
Product Development
Manager
Darren G.
Correction
Approved
Correction
Approved
Correction
Approved
Correction
Approved
GM
Exclusive Brands
Warranty
Statement
Matt B. Richard Mark Jason
Andrew I.
Correction
Approved
Product
Co-ordinator
Ruben
Nadine
Pri
Ya-Chen
Correction
Approved
Designer
GM
Marketing
Online
Merchandise
Branding
Conrm Product Specs Match Artwork
Country of Origin
Check Codes/Text
Weight Icons
Panel Direct
Warranty Spellcheck Check shadowsDie/Overprints Delete extra art
Resolution
Spec/Swatches
Supplier Contact
Add Dimensions
Check corrections
Colours/SepsBleed
Colours:
Filename:
135044 DAT Rotary Laser Red DTR30R
Date: 02/07/2019
Nicole/Jim
Dieline Pantone 166 C
Brand: DATUM Description: DAT Rotary Laser Red
Pronto:
..135044 Part#: DTR30R Barcode: 9328225049316 Country of Origin: CHN
Supplier:
000SUZHFUK Sup#: FRE203DT-RED Contact: Steven Email: steven@fukudalaser.com
50mm
60mm
MAXIMUM POWER OUTPUT < 1mW@ 635nm
Battery: 4 x 1.5V C-Cell
Ni-MH 4 x 1.2V 4000mAh
Part #: DTR30G
ROTARY
LASER
CAUTION: LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
ACCORDING TO IEC/EN 60825-1:2014
DATUM - 20 THACKRAY ROAD PORT MELBOURNE VIC 3207
SERIAL #
MADE
IN CHINA
Check piece count, headings, photos
& illustrations match on all panels
Compliance
Barcode Scans
Country of Origin
Pronto Code All Panels
Part Number All Panels
Update Details in Pronto
Supplier Contact Correct
Update Product Specication Sheet
Category
Manager
Product Development
Manager
Darren G.
Correction
Approved
Correction
Approved
Correction
Approved
Correction
Approved
GM
Exclusive Brands
Warranty
Statement
Matt B. Richard Mark Jason
Andrew I.
Correction
Approved
Product
Co-ordinator
Ruben
Nadine
Pri
Ya-Chen
Correction
Approved
Designer
GM
Marketing
Online
Merchandise
Branding
Conrm Product Specs Match Artwork
Country of Origin
Check Codes/Text
Weight Icons
Panel Direct
Warranty Spellcheck Check shadowsDie/Overprints Delete extra art
Resolution
Spec/Swatches
Supplier Contact
Add Dimensions
Check corrections
Colours/SepsBleed
Colours:
Filename:
135045 DAT Rotary Laser Green DTR30G
Date: 02/07/2019
Nicole/Jim
Dieline Pantone 166 C
Brand: DATUM Description: DAT Rotary Laser Green
Pronto:
..135045 Part#: DTR30G Barcode: 9328225049323 Country of Origin: CHN
Supplier:
000SUZHFUK Sup#: FRE203DT-GREEN Contact: Steven Email: steven@fukudalaser.com
50mm
60mm
MAXIMUM POWER OUTPUT < 5mW @ 520nm
