Datum DTR80R User Manual

6
ROTARY LASER LEVEL
COMPONENT OVERVIEW
1. Metal Lighthouse
2. Rotating laser module
3. Laser control panel
4. Up plumb dot output window
5. Rubber feet - for vertical operation
without tripod
6. 5/8” Tripod thread - for vertical operation
7. Battery compartment
2
1
3
7
8
9
5
8. Battery charging jack
(for Ni-MH battery only)
9. Down plumb dot output window
with 5/8” tripod thread - for horizontal
operation
10. Signal output window
11. Digital screen for dial-in grade
12. Remote control panel
4
6
10
11
12

Datum DTR80R Specifications

General

Brand	Datum
Model	DTR80R
Category	Measuring Instruments
Language	English
