92 Appendix E: MIDI Implementation Dave Smith Instruments
Program Data Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0010 Program Data
0000 00vv Bank Number: 0 - 9
0vvv vvvv Program Number: 0 - 99
0vvv vvvv 1024 bytes expanded to 1171 MIDI bytes in “packed MS bit” format
1111 0111 End of Exclusive (EOX)
Program Edit Buffer Data Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 0011 Edit Buffer Data
0vvv vvvv 1024 bytes expanded to 1171 MIDI bytes in “packed MS bit” format
1111 0111 End of Exclusive (EOX)
Global Parameters Data Dump
Value Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 1111 Rev2 ID
0000 1111 Main Parameter Data
0vvv vvvv 50 nibbles (LS then MS) for 25 Global parameters
1111 0111 End of Exclusive (EOX)
The Global Parameters Data Dump is not recognized when received; it is only
transmitted when requested. NRPN messages are used to change Globaqls.
