Davey RainBank KRBS1 User Manual

7
IMPORTANT
Because it involves mains water,
RainBank may only be legally
installed by a licensed plumber.
Ensure mains water pressure is
limited to 600kPa.
NOTE: Because the effects of seasonal
change etc. can cause the
pump and tank to move slightly
relevant to the home it is highly
recommended that discharge
and/or suction pipe lines be fitted
with flexible pipe, such as braided
hose, reinforced suction hose or
polythene pipe.
Different types of RainBank
Installations
There are different ways a RainBank can
be installed depending on your rainwater
tank and pump configuration.
INSTALLATION TYPE 1 - PAGE 16
Tank: above ground
Pump: outside tank
Float switch: must be installed inside
of tank
Pump Kit: KRB1, 2, 3 & 4
INSTALLATION TYPE 2 - PAGE 21
Tank: above ground
Pump: submersible inside tank
Float switch: incorporated with pump
Pump Kit: KRBS1 & 2
INSTALLATION TYPE 3 - PAGE 22
Tank: below ground
Pump: submersible inside tank
Float switch: incorporated with pumps
Pump Kit: KRBS1 & 2
Mains In
To House
Mains In
To House
FS
HOW TO INSTALL RAINBANK
!
Mains In
To Hous
e

Davey RainBank KRBS1 Specifications

General

Brand	Davey
Model	RainBank KRBS1
Category	Controller
Language	English
