Davey RVM Series - Remote Start Controller 240 V

14
Remote Start Controller 240V
76
L
SUPPLY
240 VAC
12345
N
240VAC
PUMP 1
IF PUMP HAS
CAPACITOR FITTED IN
THE LEAD INSTALL
HERE
C
SCREAM
SCR-
SCR+
N/O
COM
N/C
HLA-
HLA+
START-
START+
OVLD-
OVLD+
ALARMOVLD START HLA
ALARM CONTACT
240VAC 10 AMPS
RATED
PCB
181715 16
FLOW
SWITCH
24VAC
FROM
CONTROLLER
REMOTE
START
N/C
COM
N/O
RVM
