Davis Instruments Vantage VUE Quick Reference Guide

11
Press BAR to select:
 Barometric Pressure
Press 2ND and UNITS to change unit of measure
There are four units of measure for barometric pressure: 0.00 in, 0.0 mm, 0.0
hPa, and 0.0 mb.
Barometric Trend Arrow shows change over the last three hours:
Increase of 0.06" Hg (2.0 hPa or mb, 1.5 mm Hg) or more.
Increase of 0.02" Hg (0.7 hPa or mb, 0.5 mm Hg) or more.
Change of less than 0.02" Hg (0.7 hPa or mb, 0.5 mm Hg).
Decrease of 0.02" Hg (0.7 hPa or mb, 0.5 mm Hg) or more.
Decrease of 0.06" Hg (2.0 hPa or mb, 1.5 mm Hg) or more.
Barometer

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
