Davis Instruments Vantage VUE Quick Reference Guide

12
Press 2ND to select the second key function.
The second key function is printed above the top keys and below the bottom
keys.
The icon will appear near the time and date. After you press
another key, the icon will disappear. If you wish to select another second key
function, you must press 2ND again.
The icon will also time out and disappear from the screen if you do not press
another key within a few seconds.
Whenever you see “Press 2ND and Another Key:”
Press and release 2ND and then immediately press the other key.
Press 2nd and + or - to:
Change the console’s contrast: lighter (+) or darker (-). (The changes are
subtle and may require several presses.)
2
ND
Second

Davis Instruments Vantage VUE Specifications

General

Console Display Type	LCD
Wind Direction Range	0 to 360°
Wind Direction Accuracy	±3°
Temperature Accuracy	±1°F (±0.5°C)
Humidity Accuracy	±3%
Solar Radiation Range	0 to 1800 W/m²
Solar Radiation Accuracy	±5%
UV Index Range	0 to 16
Wireless Transmission Range	1000 feet (300 meters)
Update Interval	2.5 seconds
Temperature Range	-40°F to +150°F (-40°C to +65°C)
Humidity Range	0 to 100% RH
Rain Collector Resolution	0.01 inches (0.2 mm)
Wind Direction Resolution	1°
Power Source (Integrated Sensor Suite)	Solar panel with battery backup
Power Source (Console)	AC adapter or 3 C batteries
Wind Speed Accuracy	±2 mph (±3 kph) or ±5%, whichever is greater
Rainfall Accuracy	±4%
Operating Temperature	-40°F to +140°F (-40°C to +60°C)
Wind Speed Range	0 to 150 mph (0 to 241 km/h, 0 to 67 m/s)
