DAVIS 6410 User Manual

8
Optional: Anemometer Cable Length
Considerations
• Your anemometer includes a 40' (12
m) cable. This can be extended up to
540' (165 m) using optional extension
cables purchased from Davis
Instruments.
• If most of the anemometer cable
length is unused, the coiled cable
length can be stowed once the
anemometer has been installed on a
site. Attaching the anemometer cable
to the mounting pole using the
supplied cable tie is the recommended
option.
• Keep the anemometer cable coiled if
possible during the anemometer
assembly so that it is easily stowed
once installation is complete.
Maintenance
Your anemometer does not require any regular maintenance.
CAUTION: DO NOT attempt to lubricate the wind cup shaft and bearings or the wind vane
shaft. Natural or synthetic lubricants will inhibit the normal operation of the
anemometer.
Anemometer
Cable
Cable Tie

DAVIS 6410 Specifications

Operating Environment

operating temperature range	-40° to +149°F (-40° to +65°C)

Wind Direction

display resolution	16 points (22.5°) on compass rose, 1° in numeric display
accuracy	±3°

Wind Speed

range	2 - 200 mph, 3 - 322 kph, 2 - 173 knots, 1 - 89 m/s
accuracy	±2 mph (3 kph, 2 kts, 1 m/s) or ± 5%, whichever is greater
