DAVIS 6410 User Manual

6
Installing the Base on a Wooden Post or Surface
1. Use a drill with a 3/16" (5-mm) drill bit to make pilot holes in these locations.
2. Drive the 3" lag screws through the flat washers and the holes in the
anemometer base and into the wood.
Installing the Anemometer on a Pole or Pipe
• Use the Mounting Tripod (#7716) for easy roof-mounting.
• Use the Mounting Pole Kit (#7717) to raise the installation height by up to
37.5" (0.95 m).
• With the supplied U-bolts, the anemometer can be mounted on a pole having
an outside diameter ranging from 1
1
/
4
" to 1
3
/
4
" (32 – 44mm).
• Larger U-bolts (not supplied) can be used to mount to a pole with a maximum
outside diameter of 2
1
/
2
" (64mm).

DAVIS 6410 Specifications

Operating Environment

operating temperature range	-40° to +149°F (-40° to +65°C)

Wind Direction

display resolution	16 points (22.5°) on compass rose, 1° in numeric display
accuracy	±3°

Wind Speed

range	2 - 200 mph, 3 - 322 kph, 2 - 173 knots, 1 - 89 m/s
accuracy	±2 mph (3 kph, 2 kts, 1 m/s) or ± 5%, whichever is greater
