Page 37 of 52
Name Hex Dec Size Description
TEMP_OUT_CAL 34 52 1 The setting range is from (-12.8 °F to 12.7 °F) with the
most significant byte as the sign bit.
TEMP_CAL 35 53 15 7 "extra" temperatures, 4 soil temperatures, and 4 leaf
temperatures
HUM_IN_CAL 44 68 1 The inside humidity calibration value is ranged from 0 to
100%.
HUM_CAL 45 69 8 The first entry is the currently selected outside humidity
sensor.
DIR_CAL 4D 77 2 2 byte wind direction calibration allows full 360°
calibration in both directions.
DEFAULT_BAR_GRAPH
4F 79 1
DEFAULT_RAIN_GRAPH
50 80 1
DEFAULT_SPEED_GRAPH
51 81 1
These values control which time span to use on the
console graph display when Rain, Barometer, or Wind
Speed is shown.
ALARM_START 52 82 94 Starting location for the Alarm threshold data. See section
XIII.5 for more details on setting alarm thresholds
BAR_RISE_ALARM 52 82 1 3 hour rising bar trend alarm. Units are in Hg * 1000
BAR_FALL_ALARM 53 83 1 3 hour falling bar trend alarm. Units are in Hg * 1000
TIME_ALARM 54 84 2 Time alarm. Hours * 100 + minutes
TIME_COMP_ALARM 56 86 2 1's compliment of TIME_ALARM to validate alarm entries
LOW_TEMP_IN_ALARM 58 88 1 Threshold is (data value – 90) °F
HIGH_TEMP_IN_ALARM 59 89 1 Threshold is (data value – 90) °F
LOW_TEMP_OUT_ALARM 5A 90 1 Threshold is (data value – 90) °F
HIGH_TEMP_OUT_ALARM 5B 91 1 Threshold is (data value – 90) °F
LOW_TEMP_ALARM 5C 92 15 7 extra temps, 4 soil temps, 4 leaf temps
HIGH_TEMP_ALARM 6B 107 15 7 extra temps, 4 soil temps, 4 leaf temps
LOW_HUM_IN_ALARM 7A 122 1 Low relative humidity alarm in %.
HIGH_HUM_IN_ALARM 7B 123 1 High relative humidity alarm in %.
LOW_HUM_ALARM 7C 124 8 First entry is the current Outside Humidity setting
HIGH_HUM_ALARM 84 132 8 First entry is the current Outside Humidity setting
LOW_DEW_ALARM 8C 140 1 Threshold is (data value – 120) °F
HIGH_DEW_ALARM 8D 141 1 Threshold is (data value – 120) °F
CHILL_ALARM 8E 142 1 Threshold is (data value – 120) °F
HEAT_ALARM 8F 143 1 Threshold is (data value – 90) °F
THSW_ALARM 90 144 1 Threshold is (data value – 90) °F
SPEED_ALARM 91 145 1 Current Wind Speed alarm. Units are MPH
SPEED_10MIN_ALARM 92 146 1 10 minute average Wind Speed alarm. Units are MPH
UV_ALARM 93 147 1 Current UV index alarm. Units are (UV Index * 10)
LOW_SOIL_ALARM 95 149 4 Low soil moisture alarm in centibar. It supports four soil
moisture sensors.
HIGH_SOIL_ALARM 99 153 4 High soil moisture alarm in centibar. It supports four soil
moisture sensors.
LOW_LEAF_ALARM 9D 157 4 Low leaf wetness alarm with index 0 to 15. 0 is very dry
and 15 is very wet.
HIGH_LEAF_ALARM A1 161 4 High leaf wetness alarm with index 0 to 15. 0 is very dry
and 15 is very wet.
SOLAR_ALARM A5 165 2 Solar energy alarm is set with watts/meter
2
.
RAIN_RATE_ALARM A7 167 2 Rate rain alarm is set with inches/hour
RAIN_15MIN_ALARM A9 169 2 15-minute alarm is set with 100
th
of an inch.
RAIN_24HR_ALARM AB 171 2 24-hour alarm is set with 100
th
of an inch.
RAIN_STORM_ALARM AD 173 2 Rain storm alarm is set with 100
th
of an inch.
ET_DAY_ALARM AF 175 1 Evapotranspiration alarm is set with 1000
th
of an inch.
