Vantage Pro2 Options
2
Console Modes
The console operates in five basic modes: Setup, Current Weather, Highs
and Lows, Alarm, and Graph. Each mode lets you access a different set of
console functions or display a different aspect of your weather data.
Vantage Pro2 Options
Optional Sensors
Vantage Pro2 stations are extremely flexible. Use the following optional
sensors and wireless stations to enhance the weather monitoring capabili-
ties of your Vantage Pro2. See our website for complete details:
www.davisnet.com.
Note: Optional wireless stations can only be used with Wireless Vantage Pro2 Stations.
Optional WeatherLink
®
Software
The WeatherLink software and data logger connect your Vantage Pro2
station directly to a computer, providing enhanced weather monitoring
capabilities, a continuous preserved data record, and powerful Internet
features. The WeatherLink data logger fits neatly on the console and stores
weather data even when the computer is turned off.
Optional Sensor and Stations Description
Wireless Weather Envoy (# 6316)
Cabled Weather Envoy (# 6316C)
Performs much of the same functions as a Vantage Pro2
console, but without a display. Use an Envoy to interface your
wireless station to a computer when you’d rather place the
console in another location for viewing weather conditions
Anemometer Transmitter Kit
(# 6332)
Provides more flexible anemometer placement for wireless
stations.
Wireless Leaf & Soil Moisture/
Temperature Station (# 6345)
Measures and transmits leaf wetness, soil moisture and
temperature data. Also for use with GLOBE.
Wireless Temperature Station
(# 6372)
Measures and transmits temperature data.
Wireless Temperature/Humidity
Station (# 6382)
Measures and transmits air temperature and humidity data.
Solar Radiation Sensor (# 6450)
Measures solar radiation. Required for calculating
evapotranspiration (ET). Available for cabled and wireless
stations. Requires Sensor Mounting Shelf (# 6673).
Ultraviolet (UV) Radiation Sensor
(# 6490)
Measures UV radiation. Required for calculating the UV dose.
Available for Cabled and Wireless stations. Requires Sensor
Mounting Shelf (# 6673).
WeatherLink Option Description
WeatherLink for Windows, USB
connection (# 6510USB)
Includes WeatherLink software and USB data logger. Allows you to
save and view your weather data on your PC.
WeatherLink for Windows, serial
connection (# 6510SER)
Includes WeatherLink software and serial data logger. Allows you to
save and view your weather data on your PC.
