52
shown, the console is configured to listen directly to a station and not to a
repeater.
In the example below, the console is set up to receive an ISS station on
transmitter ID 1 from repeater A.
6. For each station using a repeater, select the station and turn on the repeater
function and select the correct repeater ID.
7. Press DONE to continue to the other screens in the Setup Mode, or press
and hold DONE to return to the Current Weather Mode.
Note: In console with the October 2005 version of firmware, the only way to exit Repeater Setup mode is
to press DONE to continue to the next setup screen.
Verifying Setup
To verify that you have successfully set up your console to receive a repeater
in the console’s Current Weather Mode:
1. View the transmitter information displaying at the bottom of the
console screen.
If the transmitter ID being repeated is displayed and an “X” flashes in the
bottom right corner of the ticker tape, the transmitter is being repeated and
received by the console successfully.
The repeater’s information also displays at the bottom of the console’s
diagnostics screens.
Clearing Repeater ID
If a repeater ID is being displayed in Screen 2 and you are not using a repeater
with the selected station, you must turn off the repeater function to receive sta-
tion information successfully.
In Setup Screen 2:
For consoles with May 2005 firmware, press WIND repeatedly so that the
console cycles through the list of repeater IDs (Repeaters A-H) until the sec-
tion where the repeater ID was displayed is blank. Press DONE to continue to
the next screen or press and hold DONE to return to the Current Weather
Mode.
For consoles with October 2005 firmware, press 2ND and then press WIND
repeatedly so that the console cycles through the list of repeater IDs (Repeat-
ers A-H) until the section where the repeater ID was displayed is blank. Press
DONE to continue to the next screen or press and hold DONE to return to the
Current Weather Mode.
