Selecting Units of Measure
19
Selecting Units of Measure
Most weather variables may be displayed in at least two different measure-
ment units, including US and Metric systems, although some variables feature
more possibilities. Barometric pressure, for example, may be displayed in mil-
libars, millimeters, inches, or hectoPascals. Note that you can set each vari-
able’s units independently, and at any time, as you like.
To change units:
1. Select the weather variable. See “Selecting Weather Variables” on page 18.
2. Press and release 2ND then press UNITS.
The selected variable’s units will change. Repeat steps 1
and 2 until the desired units appear.
For example, to change the Barometric pressure units, first select Baromet-
ric pressure by pressing BAR. Next, press and release 2ND, then press
UNITS. Repeating these steps cycles through the units available for Baro-
metric pressure: millibars, millimeters, inches, and hectoPascals.
Wind Speed and Direction
1. Press WIND to select wind speed.
2. Wind speed may be displayed in miles per hour (m.p.h.), kilo-
meters per hour (km/h), meters per second (m/s), and knots
(knots). The 10 minute average wind speed will be displayed in
the ticker.
A solid arrow within the compass rose indicates the current wind direction.
Arrow caps indicate up to six different 10-minute dominant wind directions
to provide a history of the dominant wind directions for the past hour.
N
W
NE
SESW
Vertical Scale: X10
WIND
RAIN YEAR
in
TEMP OUT
HUM IN
HUM OUT
DAILY RAIN
in
TEMP IN
hPa
BAROMETER
STATION NO.1
F
F
F
MPH
Last 24 hrs
hr
Every 1
S
E
NW
pm
TEMP IN
F
TEMP OUT
F
HEAT INDEX
N
W
NE
SESW
WIND
MPH
E
S
NW
2
ND
GRAPH
UNITS
BAROMETER
mb
BAROMETER
BAROMETER
mm
in
Displaying Units:
Barometric Pressure Units: millibars (mb), millimeters (mm) and inches (in)
WIND
