08 09
CONTROL PANEL
The control panel consists of two function
operators. One is a timer knob, and another
a power knob.
POWER/ACTION SELECTOR
You use this operator knob to choose a
cooking power level. It is the rst step to
start a cooking session.
TIMER KNOB
Offer visual timing settings at easy turn of
your thumb to select a desired cooking time
up to 30 minutes per cooking session.
MICROWAVE COOKING
For pure microwave cooking, there are six
power levels from which to choose one as
best t to do the job at hand.
Power level increases with the knob turning
clockwise. The power levels can be
classied as the following:
PART NAMES
1. Door Safety Lock System
2. Oven Window
3. Roller Ring
4. Shaft
5. Control Panel
6. Wave Guide
(Please do not remove the mica plate covering the wave guide)
7. Glass Tray
Power Output
100%
88%
73%
52%
42%
20%
Description
HIGH
M.HIGH
MED
M.LOW
DEFROST
LOW
1
2
3
4
5
6
