21Page
1
100898-01 Micrometer Arm
1
2
100898-02 Micrometer Base
1
3 100898-03
Micrometer Suspension Flange
1
4
91253A189
8-32 x 1/4 HSFHS 4
D105 Micrometer Mount Assembly (101788)
Item Part Number
Description Qty
3
1
2
4
1
11 94052A133
Push-On Cap
1
Item Part No. Description
Qty
Coupling Stop Assy (100954)
11
10
5
4
6
7
8
9
2
4
1
3
1 100950 Coupling Stop Block 1
2 98381A544
Stop Block Pin
2
3 100951
Stop Block Rod
1
4 91251A540
1/4-20 X 3/4 SHCS
2
5 9489T47 Eye Bolt 1
6 100952
Adjustable Stop Arm
1
7 DK-655 Knob 1
8 100953
Fixed Stop Arm
1
9 94750A588
T-Nut (1/4-20)
1
10 90126A029
1/4 Flat Washer
COMPONENT PARTS BREAKDOWN
