OPERA REEVO Cod. 420120426 REV. 1.0
ACOUSTIC COVERAGE
The two models have the following acoustic coverage:
OPERA REEVO 210 100°x60° (HxV)
OPERA REEVO 212 100°x50° (HxV)
MECHANICAL FEATURES
Both models have two handles (A) for easy transport, one on the right side and one on the top. Three attachment
points for lifting with eyebolts (B) and the provision for pole mounting (C) ensure that the speaker is ergonomic
and quick to mount.
B
B
B
C
A
A
H
V
