dbx 231s - Section 3: Connecting the EQ to Your System; Rack Mounting and Environment; Audio Connection Best Practices

8
FREQUENCYBANDCENTERSOFTHESANDSAREMARKEDATRDOFANOCTAVEINTERVALS
on ISO standard spacings, while the frequency band centers of the 215s are marked at
RDSOFANOCTAVEINTERVALSON)3/STANDARDSPACINGS
Low Cut Enable Switch
The LOW-CUT switch inserts or removes the 12 dB per octave 50 Hz low-cut filter from
the signal path. When the LOW-CUT switch is pushed in, the LOW-CUT filter is IN the
audio path.
Section 3 - Connecting the EQ to Your System
The 2-Series Equalizers have balanced inputs and impedance balanced outputs that can
be used with any balanced or unbalanced line-level device.
To connect the equalizer to your sound system refer to the following steps:
r5VSOPGGBMMFRVJQNFOUCFGPSFNBLJOHDPOOFDUJPOT
r.PVOUFRVBMJ[FSJOBTUBOEBSEXJEUISBDL
Install the EQ in a rack with the rack screws provided. It can be mounted above
or below anything that does not generate excessive heat. Ambient temperatures
should not exceed 113° F (45°C) when equipment is in use. Although the unit’s
chassis is shielded against radio frequency and electromagnetic interference,
extremely high fields of RF and EMI should be avoided.
r .BLFBVEJPDPOOFDUJPOTWJB9-3PS534KBDLTBDDPSEJOHUPBQQMJDBUJPO 
 OFFET
Both types of connectors for the inputs and outputs can be used for balanced or
unbalanced connections. The use of more than one connector at a time for the
inputs could unbalance balanced lines, cause phase cancellation, short a conduc-
tor to ground, or cause damage to other equipment connected to the equalizer.
More than one output may be used simultaneously as long as the combined paral-
lel load is greater than 2 k7.
r 4FMFDUUIFPQFSBUJOHSBOHFXJUIUIF#PPTU$VUSBOHFTFMFDUJPOTXJUDI
/05&#FTVSFUPSFEVDFBVEJPMFWFMTBUUIFQPXFSBNQMJGJFSTXIFODIBOHJOH
UIFTFUUJOHPGUIJTTXJUDIBTJUNBZHFOFSBUFBOBVEJCMFUSBOTJFOU
r"QQMZQPXFSUPUIFFRVBMJ[FS
Connect the AC power cord to the AC power receptacle on the back of the equal-
izer. Route the AC power cord to a convenient power outlet away from audio lines.
User Manual
2-Series
