Receive Key Accepted (56h)
SYS_HEAD, 56(h), cc1, cc2, F7(h)
cc Code echoed for the Key Scan received. (00(h) if key is invalid)
The Receive Key Accepted procedure is sent from the DDP in response and acceptance of a Receive Scan Code
Key or Receive Hold Scan Code Key procedure but is ignored if received by the DDP.
Reset Program (20h)
SYS_HEAD, 20(h), F7(h)
The Reset Program procedure causes the DDP to reload the current saved program.
Reset Device (21h)
SYS_HEAD, 21(h), F7(h)
The Reset Device procedure causes the DDP to reboot the software as if the power had been turned off, and then
back on. If edits have been made to the current program without saving, they will be lost.
SysEx Setup Dump Sample
Following is a simple example of a SysEx Setup dump. It takes you set by step through all of the operation com-
mands of a typical SysEx procedure.
<<SysEx Header>>
F0 00 01 1E 00 01
<<Procedure>>
43
<<Setup Dump Version>>
00 01 00 01
<<Setup Type and Setup Number>>
00 00 00 00
<<Setup Transmit Count...Lo Bytes, Hi Bytes>>
00 0A 00 06
<<12 Character Setup Name...dynamic>>
00 31 00 3A 00 52 00 76 00 62 00 20 00 32 00 3A 00 47 00 74 00 52 00 76
<<Null to indicate end of Character String>>
00 00
<<Misc Setup Data...too dynamic to document>>
00 07 00 00 00 06 00 00 00 03 00 06 00 03 00 32 00 08 00 03 00 00 00 00 00 02 00 04 00 00 00 00 00 02
00 08 00 00 00 00 01 7E 00 00 00 00 00 20 01 7F 00 00 00 00 00 20 00 00 00 00 00 00 00 20 00 01 00 00
00 00 00 20 00 02 00 00 00 00 00 20 00 00 00 00 00 00 00 00 00 00 00 00 00 00
<<SysEx End>>
F7
