DriveRack® User Manual
7.2- Stereo Tri-amp
Hardware
1. Connect the outputs from the mixer to the inputs of the DriveRack.
2. Connect the outputs of the DriveRack and run to the selected speaker amplifier.
3. Making sure that all outputs are muted, apply power to the mixer and amplifiers.
Software
1. Select a program (Factory: 2x6 Stereo) as a template.
2. Load the program by pressing the PROG/CONFIG button.
3. Adjust the individual parameters for the system by pressing the Processing Module
buttons
2 3 4 5
JBL SR4731X
JBL 4719X
Left
Right
MA-5002VZ
Section 7
Application Guide
