72
DriveRack
®
DriveRack® User Manual
Appendix A
A.8 Input and Output Diagrams
1-4
Input 1 Gain
DSP
DSP Input 1
Euroblock
DSP Input 2
XLR 1
XLR 2
Input 2 Gain
Input 1 Gain
Input 2 Gain
5
6
Appendix
