Specifications
ANALOG INPUTS
Number of Inputs: 2 line inputs, 1 RTA mic input
Connectors: 2 female XLR line inputs, 1 female XLR RTA mic input
Type: Electronically balanced/RF filtered
Impedance: > 50 kΩ
Max Input Level (line inputs): > +20 dBu
CMRR: > 45 dB
RTA Mic Preamp Phantom Power: +15 VDC
ANALOG OUTPUTS
Number of Outputs: 6 line outputs
Connectors: Male XLR
Type: Electronically balanced, RF filtered
Impedance: 120 Ω
Max Output Level: +20 dBu
Alignment Delay: Up to 10ms per output channel pair
A/D PERFORMANCE
A/D Converter: 24-bit with dbx Type IV™ Conversion System
A/D Dynamic Range: 112 dB A-weighted, 110 dB unweighted
Type IV Dynamic Range: 123 dB with transient material, A-weighted, 22kHz BW;
121 dB with transient material, unweighted, 22kHz BW;
115 dB typical with program material, A-weighted, 22kHz BW
D/A PERFORMANCE
D/A Converter: 24-bit
D/A Dynamic Range: 112 dB A-weighted, 110 dB unweighted
SYSTEM PERFORMANCE
Internal Processing Wordlength: 32-bit floating point
Sample Rate: 48 kHz
Dynamic Range: 110 dB A-weighted
107 dB unweighted
THD+Noise: 0.003% typical at +4 dBu, 1 kHz, 0 dB input gain
Frequency Response: 20 Hz – 20 kHz, +0 /- 0.5 dB
Interchannel Crosstalk: < -110 dB, -120 dB typical (input-to-output: < -100 dB)
Latency: Input to output: 1.847 ms
POWER SUPPLY
Operating Voltage: 100-120 VAC 50/60 Hz or 220-240 VAC 50/60 Hz
Power Consumption: 22 Watts
PHYSICAL
Unit Weight: 5.25 lbs. (2.4 kg)
Shipping Weight: 6.75 lbs. (3.1 kg)
Dimensions: 1.75” (H) x 5.75” (D) x 19” (W)
4.4cm (H) x 14.6cm (D) x 48.26cm (W)
Specifications are subject to change without notice.
