Specifications
INPUTS
Mic/Line
Number of Inputs: 2, independently switchable between mic or line level
Connectors: Female ¼” - XLR combination
Type: Electronically balanced, RF filtered
Impedance: Switch set to MIC: 2 kΩ balanced, Switch set to LINE: 22 kΩ balanced
Max Gain: Switch set to MIC: 48 dB, Switch set to LINE: 5 dB
Max Input Level: Switch set to MIC: 0 dBu, Switch set to LINE: +20 dBu
CMRR: > 45 dB
Aux
Number of Inputs: 1
Connector: Female stereo 1/8” (3.5 mm) TRS mini
Type: Unbalanced, RF filtered
Impedance: 20 kΩ
Max Input Level: +20 dBu
OUTPUTS
Number of Outputs: 2 line outputs
Connectors: Male XLR
Type: Impedance balanced, RF filtered
Impedance: 40 Ω
Max Output Level: +14 dBu
MIC/LINE A/D & D/A PERFORMANCE
Converters: 24-bit
Dynamic Range: 115 dB A-weighted
AUX INPUT A/D PERFORMANCE
D/A Converter: 24-bit
D/A Dynamic Range: 106 dB A-weighted
SYSTEM PERFORMANCE
Internal Processing Wordlength: 32-bit floating point
Sample Rate: 48 kHz
Dynamic Range: 103.5 dB A-weighted
102.5 dB unweighted
THD+Noise: 0.04% typical at 0 dBu in/out, 1 kHz
Frequency Response: 20 Hz – 20 kHz, +0 /- 0.5 dB
Interchannel Crosstalk: < -80 dB, -84 dB typical
Latency: Input to output: 3.4 ms
POWER SUPPLY
Model: PS0913DC-04 (9 VDC)
Operating Voltage: 100-240 VAC, 50/60 Hz
Power Consumption: 4.5 Watts (500 mA)
PHYSICAL
Unit Weight: 1.2 lbs. (0.54 kg)
Shipping Weight: 2.04 lbs. (0.93 kg)
Dimensions: 6.1” (L) x 4.1” (W) x 1.69” (H)
154.9 mm (L) x 104.1 mm (W) x 42.9 mm (H)
Specifications subject to change without notice.
