Section 3 - Wiring
3.1 ZonePro Wiring
Zone Controller Installation
The installation of the Zone Controllers MUST be accomplished with the use of cable which is
rated VW-1 or higher. Common NEC designations which meet this rating include: CMP, CMR,
CMG, CM and CMX.
ZC-1 - The ZC-1 is a programmable zone controller that allows input or output volume level
control from a wall panel.
ZC-2 - The ZC-2 is a programmable zone controller that allows input or output volume level
and mute control from a wall panel.
ZC-3 - The ZC-3 allows wall panel routing and Actions selection for the SC devices.
ZC-4 - The ZC-4 provides contact closure routing and Actions selection for room combining or
fire safety applications.
ZC-Fire - The ZC-Fire is the interface to generic fire alarm relays. When fire alarm activates,
the general purpose relay can typically be programmed to close if normally open or
vices-versa. The ZC-fire interface unit monitors the state of the relay (n.o. or n.c.) and upon
the state of change, notifies the SC 32/64, which then mutes its outputs.
ZC-6 - The ZC-6 is a push-button up and down input or output volume controller.
ZC-7 - The ZC-7 allows Actions selection for the SC devices.
ZC-8 - The ZC-8 is used for a combination of input or output volume up/down, and four
position source/program select.
ZC-9 - The ZC-9 allows wall panel routing and Actions selection for the SC devices.
ZC-BOB - The ZC-BOB allows parallel or home run cabling of the Zone Controllers.
