Appendix
Technical Specifications
16
1260/1261
Analog Inputs:
Number of Inputs: 12 Total (2) Switchable mic or line, (8) RCA, and (1) S/PDIF
Connectors: Euroblock (Line and Mic), RCA (Source) and RCA (S/PDIF)
Type: Electronically balanced, RF filtered
Impedance (Euroblock): > 50 kΩ Balanced, >25 kΩ Unbalanced, RF Filtered
Impedance (RCA): >25 kΩ Unbalanced, RF Filtered
Max input line level: +20 dBu Mic/Line, +12 dBu RCA
CMRR: > 40 dB, typically >55 dB @ 1 kHz
Mic Pre gain: 30 to 60 dB
Mic EIN: > 118 dB, 22 Hz-22 kHz, 150 Ω Source Impedance
Mic Phantom Power: 15 V
Analog Outputs:
Number of Outputs: 6
Connectors: Euroblock
Type: Electronically balanced, RF filtered
Impedance: 120 Ω balanced, 60 Ω unbalanced
Max Output Level: +20 dBu
A/D Performance:
Type: dbx Type IV™ conversion system
Dynamic Range line: >113 dB A-weighted, >110 dB unweighted
Type IV dynamic range: >119 dB, A-weighted, 22 kHz BW>117 dB, unweighted, 22
kHz BW
Sample Rate: 48 kHz
D/A Performance:
Dynamic Range: 112 dB A-weighted, 109 dB unweighted
System Performance:
Dynamic Range: >110 dB A-weighted, >107 dB unweighted,
THD+N: 0.003% typical at +4 dBu, 1 kHz, 0 dB gain
Frequency Response: 20 Hz – 20 kHz, +/- 0.5 dB
Interchannel Crosstalk: >80 dB typical
Crosstalk input to output: >80 dB
Propagation Delay: 0.6 msec
Operating voltage: 100-240 VAC, 50/60Hz
Power Requirements: 27 Watts
Physical:
Weight: 6.0 lbs.(2.7 kg) Shipping weight 8.0 lbs. (3.6 kg)
Dimensions: 1.75” H x 8” D x 19” W
ZonePro
TM
dbx® incorporates high quality
mechanical fans in some products. All
mechanical fans have a limited life
expectancy. We recommend annual
inspection of fans for dust occlusion
and excessive noise. Fan assemblies
should be replaced after six to ten
years of use. Environmental factors
such as elevated temperature, dust,
and smoke can adversely affect
fan life. Systems exposed to these
conditions should be inspected more
frequently. Fan replacement can be
performed either at the factory or by
an experienced technician in the field.
Please contact dbx Technical Support
for more information on purchasing
replacement parts or product service.
dbx® has a policy of continued product
improvement and accordingly reserves
the right to change features and
specifications without prior notice.
