18
ZonePro
TM
1260m/1261m
Analog Inputs:
Number of Inputs: 10 Total (6) Switchable mic or line, (4) RCA, and (1) S/PDIF
Connectors: Euroblock (Line and Mic), RCA (Source) and RCA (S/PDIF)
Type: Electronically balanced, RF filtered
Impedance (Euroblock): > 50 kΩ Balanced, >25 kΩ Unbalanced, RF Filtered
Impedance (RCA): >25 kΩ Unbalanced, RF Filtered
Max input line level: +20 dBu Mic/Line, +12 dBu RCA
CMRR: > 40 dB, typically >55 db @ 1kHz
Mic Pre gain: 30 to 60 dB
Mic EIN: > 118 dB, 22 Hz-22 kHz, 150 Ω Source Impedance
Mic Phantom Power: 15 V
Analog Outputs:
Number of Outputs: 6
Connectors: Euroblock
Type: Electronically balanced, RF filtered
Impedance: 120 Ω balanced, 60 Ω unbalanced
Max Output Level: +20 dBu
A/D Performance:
Type: dbx Type IV™ conversion system
Dynamic Range line: >113 dB A-weighted, >110 dB unweighted
Type IV dynamic range: >119 dB, A-weighted, 22 kHz BW>117 dB, unweighted, 22 kHz BW
Sample Rate: 48 kHz
D/A Performance:
Dynamic Range: 112 dB A-weighted, 109dB unweighted
System Performance:
Dynamic Range: >110 dB A-weighted, >107 dB unweighted,
THD+N: 0.003% typical at +4 dBu, 1 kHz, 0 dB gain
Frequency Response: 20 Hz – 20 kHz, +/- 0.5 dB
Interchannel Crosstalk: >80 dB typical
Crosstalk input to output: >80 dB
Propagation Delay: 0.6 msec
Operating voltage: 100-240 VAC, 50/60Hz
Power Requirements: 27 Watts
Physical:
Weight: 6.0 lbs.(2.7 kg) Shipping weight 8.0 lbs. (3.6 kg)
Dimensions: 1.75” H x 8” D x 19” W
Appendix
Technical Specifications
