DCB EST-9600 - Ethernet Port; Setup Port

23
Ethernet Port
Pin Signal In/Out
1 Transmit OUT
2 Transmit OUT
3 Receive IN
6 Receive IN
Setup Port
RS-232 (RJ-45)
Pin Signal In/Out
1 Data Set Ready OUT
2 Data Carrier Detect OUT
3 Busy IN
4 Signal Ground -----
5 Receive Data OUT
6 Transmit Data IN
7 Clear to Send OUT
8 Request to Send IN
