DCB EST-9600 - Section 3 - Controls and Indicators

6
3. CONTROLS AND INDICATORS
CONTROLS
DIP Switches
Switch Down Up
1 Normal Reset
2 Setup Port Inactive Setup Port Active
3 Must be Down
4 Must be Down
INDICATORS
Front
Indicator Condition Meaning
Power ON Power to unit
Status OFF
ON
Set for Internal Clock
Set for External Clock
Sync Flashing Sync Port Data Activity
Setup Flashing Setup Port Data Activity
Rear
Indicator Condition Meaning
Top Flashing LAN activity present
Bottom ON Good LAN connection
