SPECIFICATION
Clock type
Class 1 Master Clock, featuring dual crystal oscillators with microcontroller-
enhanced temperature correction.
Clock Frequencies
44.1 and 48kHz.
Clock Accuracy
Better than +/-1ppm when shipped, typically +/-0.1ppm when shipped and
stabilised. The calibration is stable over a temperature range of +5°C to
+55°C.
Word Clock Outputs
Three independently buffered, TTL-compatible outputs on 75Ω BNC
connectors.
• Output 1: fixed at 44.1kHz
• Output 2: fixed at 48kHz
• Output 3: set to 44.1kHz at power up, RS232 controllable.
Start-up time
Typically 1 minute to rated accuracy.
Size and weight
444mm (17.5”) long x 435mm (17.2”) deep x 64mm (2.6”) high. Allow extra
depth for cable connectors.
8.3kg (18.3lbs).
Power requirements
Internally set to either 100, 115/120, 220 or 230/240V AC, 49 – 62Hz.
Power consumption: 3W typical, 50W maximum.
Consumes less than 0.5W when powered down from the front panel.
These specifications are subject to change without notice.
