Dea 203RR - Page 23

R
203 RR
Operating instructions and warnings
21
PROCEDURE DESCRIPTION
PROCEDURE
P001
Positioning of gate/door
P002
Unused parameter
P003
Memorization of the motor stroke
P004
Deletion of the radio receiver memory
P005
Memorization of transmitters
P006
Search and deletion of a transmitter
P007
Resetting of default parameters
PARAMETER DESCRIPTION SETTABLE VALUES
1
USER
2
PARAMETRES
P008
Type of coding of the radio receiver
000
HCS fixed part only
001
HCS rolling code
002
HT12E dip switch
P009
Channel selection and linking to “start” and “pedestrian” inputs
START
PEDE-
STRIAN
START
PEDE-
STRIAN
001
CH1 CH2
009
CH3 CH4
002
CH1 CH3
010
CH4 CH1
003
CH1 CH4
011
CH4 CH2
004
CH2 CH1
012
CH4 CH3
005
CH2 CH3
013
CH1 CH2
3
006
CH2 CH4
014
CH2 CH2
3
007
CH3 CH1
015
CH3 CH2
3
008
CH3 CH2
016
CH4 CH2
3
P010
Motor speed during normal stroke (calculated as % of max speed)
50 ....................... 100
P011
Motor speed during slow-down phase (calculated as % of max speed)
30............ 60.................. 100
P012
Slow-down duration (expressed as % of total stroke)
10 ....25
.........50
P013
P014
Motor force in opening (if =100 --> max force, obstacle impact sensibility deactivated)
30..............................90
..100
P015
Motor force in closing (if =100 --> max force, obstacle impact sensibility deactivated)
30..............................90
..100
P016
P017
Unused parameter
P018
Selection of type of external safety device: rib / barrier. If the “rib” mode is selected, when the CST input is activated the movement direction is inverted; If the “barrier” mode is selected, when the CST input is activated the movement is stopped.
000
safety ribs mode
001
photoelectric barriers mode
