203 RR
R
Operating instructions and warnings
22
P019
Time of automatic closing (expressed in sec). If = 0 the automatic closing is deactivated
0 10 .............................................. 255
P020
Time of pre-flashing (expressed in sec)
0..... 2 .............................................. 15
P021
Unused parameter
P022
Unused parameter
P023
Collectivity function: if it is activated it deactivates both start and pedestrian inputs for
the whole duration of automatic opening and closing
000
deactivated
001
activated
P024
Ram blow function: if it is activated, it pushes the motors close for one second before
each opening movement, so as to ease the releasing of any electric lock
000
deactivated
001
activated
P025
Operating program: reversal (start->open, start->close, start->open ...), step-by-
step (start->open, start->stop, start-close...)
000
inversion
001
step-by-step
P026
Photocell function even while opening: if it is activated, the photocell stops the
movement while opening until the obstacle is removed. In any case it reverses the
direction of movement while closing
000
Photocell activated only in closing
001
Photocell activated also in
opening
P027
Clean contact operation : - If = 0, open gate warning light, the contact is always
closed when the gate is opened, it opens again only when the closing movement is
completed - If ≠ 0, courtesy light, the contact is closed during every movement, it
opens again when the motor stops according to a pre-settable delay (expressed in sec)
0.................................................... 255
P028
Short reversal at end of stroke: when the gate/door reaches the end of stroke, it
reverses shortly the movement so as to “release” the mechanical stress due to the gate/
door’s pressure on the end of stroke itself.
000
deactivated
001
activated
P029
Unused parameter
P030
“PED” input functioning -If = 0 it ensures the door/gate closing in any situation. The
input opens and works normally -If = 1 the “PED” input starts the closing, the “AP” input
starts the opening -If >1 The selected value indicates the duration of the pedestrian
stroke (expressed as a % of the total stroke)
000
Central lock
001
Separate lock
>001
Pedestrian
P031
Limitation of motor force when it reaches the end of stroke while closing - If = 0,
limitation is disabled (force level at the end of stroke is set automatically) - If different
from 0, it indicates the force value (expressed as a % of the max value) the motor exerts
at the end of stroke while closing.
0.................................................... 100
P032
Reaction at detection of an obstacle while opening - If=0 the door inverses travelling
direction - If different from 0 the door inverses travelling direction only for the set time
(expressed in sec)
0...................................................... 10
P033
Reaction at detection of an obstacle while closing -If=0 the door reverses travelling
direction -If different from 0 0 the door reverses travelling direction only for the time set
(expressed in sec)
0...................................................... 10
P034
Unused parameter
1
The default value set by manufacturer at the factory is written underlined.
2
Column reserved to the installer to fill in with the automation personalised parameters Table 2 Parameters
3
Inactive channel.
