OPERATING PARAMETERS
Operators speed adjustment during the stroke while opening 30%tot........................100%tot Operators speed adjustment during the stroke while closing 30%tot........................100%tot Operators speed adjustment during slow-down while opening and closing 15%tot........................100%tot Slow down duration adjustment while opening 5%tot............................75%to Slow down duration adjustment while closing 5%tot............................75%tot Operator 1 force adjustment while opening (if = 100% obstacle detection deactivated)
10%tot…...........................50%tot
Operator n.1 force adjustment while closing (if = 100% obstacle detection deactivated)
10%tot…...........................50%tot
Operator n.2 force adjustment while opening (if = 100% obstacle detection deactivated)
10%tot…...........................50%tot
Operator n.2 force adjustment while closing (if = 100% obstacle detection deactivated)
10%tot…...........................50%tot
Automatic closing times adjustment (if = 0 automatic closing deactivated)
0sec...................................255sec
Pedestrian automatic closing time adjustment (se = 0 pedestrian automatic closing deactivated)
0sec...................................255sec
Pedestrian stroke duration adjustment 5%tot…...........................100%tot Pre-flashing time adjustment 0sec…….10sec Adjustment of phase displacement time while opening 0sec……………30sec Adjustment of phase displacement time while closing 0sec……………30sec Collectivity function: if it is activated it deactivates both opening and closing inputs for the whole duration of automatic opening and closing •000:“collectivityfunction”deactivated
•001:“collectivityfunction”activated
Ram blow function: it pushes the motors closed for one second before each opening movement, so as to ease the electric-lock release •000:“ramblow”deactivated
•001:“ramblowfunction”activated
“Reversal” mode selection (during the manoeuvre a command impulse reverse the mouvement) or “step by step” (during the manoeuvre a command impulse stops the mouvement). A next impulse restart the operator to the opposite direction.
•000:“reversalfunction” •001:“stepbystepfunction”
PHOTO input functioning: if=0 photocells are enabled while closing and at start when gate is closed; if=1 photocells are always enabled; if=2 photocells are enabled while closing only. When enabled, its activation provokes: the inversion (while closing), the stop (while opening) and prevent the starting (when gate is closed).
•000:photocellsenabledwhileclosingandatgateclosed •001:photocellsalwaysenabled •002:photocellsenabledonlywhileclosing
Selection of functioning mode : “warning light” (output is ON at gate opened, OFF at the end of the closing manoeuvre) or “courtesy light” (output is ON during every mouvement, OFF when the operator stops according to a pre-settable delay.
•000:“warninglight” •>000:“courtesylight”offdelay(1sec………………255sec)
Searches for end of stroke while opening too: when activated, operators stop only at their arrival et the end of stroke, also while opening. •000:Stopwhenopeningonamemorizedpoint
•001:Stopwhenopeningontheendofstroke
“soft start” function: motors accelerate gradually until they reach the set speed, avoiding sudden departures •000:“softstart”deactivated
•001:“softstart”activated
Lenghtadjustmentofreversalonobstacle:if=0itexecutesacompletereversal,if>0indicatestheduration(inseconds)ofthestrokeafterinversioncausedbythe detection of an obstacle during opening.
•000:completereversalonobstacle •>000:durationofreversalonobstacle (1sec……………..10sec)
Lenghtadjustmentofreversalonobstacle:if=0itexecutesacompletereversal,if>0indicatestheduration(inseconds)ofthestrokeafterinversioncausedbythe detection of an obstacle during closing.
•000:completereversalonobstacle •>000:durationofreversalonobstacle (1sec……………..10sec)
Facilitationmanualrelease:If≠0,afterdetectingthelockingstop,theenginereversesforabrieftimetoreleasethepressureonit,andthusfacilitatethemanual release. The set value shows the length of the inversion. If=0 function disabled
•000:facilitatingreleasedisabled •>000:facilitationactivatedwithreleasetimeequalto: (1x25ms……………..10x25ms)
Unused parameter Unused parameter Unused parameter Unused parameter
